Total 600V Clamp Meter Electrical Testing Device
Total 600V Clamp Meter Electrical Testing Device
Couldn't load pickup availability
Product Name: 600V Total Electrical Clamp Meter
Digital AC Clamp Meter DM600V CAT.III TMT46004
- This multimeter is designed according to the international standard (IEC 61010) for electronic measuring instruments with overvoltage and power interference class.
- LCD display, with four-bar readout
- A key to switch readings with clear, raised lettering and easy thumb switching.
- Button to turn on the screen backlight
- Jaw length 5 cm with an opening angle of 30 degrees
- 9cm inspection pins with 75cm wire
- It operates on 2 AAA batteries.
- It supports DC/AC voltage, resistance, and current continuity as follows:
| Type | Reading range | Accuracy |
| DC Voltage | 0 - 600 volts | ±(0.5% +3) |
| AC Voltage | 1.0 - 600 volts | ±(0.8% +5) |
| AC Current 1 | 2mA-400A | ±(0.5% +2.5) |
| AC Current 2 | 400A-600A | ±(0.5% +3) |
| Resistance | 60kΩ | ±(0.8% +3) |
|
Dimensions of the entire device (in centimeters) |
19 × 5 × 3.5 |
| Length of the testing wire (centimeter) | 75 |
| Screen dimensions | 3.5 × 2.3 |
|
the color |
Red and blue |
| Weight (grams) | 240 |
|
Model number |
TMT46004 |
